Product Introduction

The ESN1000 Conductivity Analyzer determines the conductivity of a solution by measuring its ability to conduct electricity. The conductivity of a solution is closely related to its ion concentration and temperature. The instrument typically applies an alternating voltage across two electrodes and measures the current to calculate conductivity. Proper selection and use ensure accurate measurement results.

Instrument Features
  • Digital sensor with strong anti-interference ability
  • Real-time monitoring with fast response;
  • Supports immersion and pipeline installation.
Typical Applications


Wastewater treatment, drinking water treatment, surface water monitoring, pollution source monitoring, and process industries such as electronics, electroplating, chemistry, food, and pharmaceuticals


Wastewater Treatment
Surface Water Monitoring
Drinking Water Treatment
Pollution Source Monitoring


Technical Specifications
Display 7-inch screen (resolution 1024*600) Power Supply & Consumption 220VAC <10W; 24VDC<300mA
Signal Output RS485*1; 4-20mA output*1 Relay 1 channel
Construction Material & Protection Class ABS; IP65  Dimensions & Weight 230*180*100 (L*W*D); 2kg
Operating Temperature 0-45°C, water sample temperature 0-50°C Measurement Method Temperature: Thermistor method; Conductivity: Graphite electrode method
Range/Resolution Temperature: 0-100°C; 0.01°C Comparison Error (Measurement Accuracy) Temperature: ±0.3°C
Conductivity: 0-20000μS/cm; 0.01μS/cm Conductivity: ±1%
Repeatability Temperature: ±0.2°C Lower Detection Limit Conductivity: 0.1μS/cm
Conductivity: ±1% *******
